Additional information
| CPU Support | Supports 10th Gen Intel® Core™ / Pentium® Gold / Celeron® processors |
|---|---|
| CPU Socket | LGA 1200 |
| Chipset | Intel® B460 Express Chipset |
| Graphics Interface | 1 x PCIe 3.0 x16 Slots |
| Display Interface | HDMI |
| Memory Support | 4 DIMMs, Dual Channel DDR4 up to 2666MHz (128GB Max) |
| Expansion Slots | 2 x PCIe x 1 slots |
| Storage | 1 x M.2 Socket 3 (both SATA & PCIe mode), 6 x SATA 6Gb/s gray |
| SATA RAID | RAID 0, 1, 5, 10 for SATA Storage Devices |
| USB Ports | 6 x USB 3.2 (Gen1), 2 x USB 2.0/1.1 ports |
| LAN | Realtek® GbE LAN chip (1000 Mbit/100 Mbit) |
| Wireless + Bluetooth | Wi-Fi 802.11a/b/g/n/ac and Bluetooth 4.2 |
| Audio | 8-Channel (7.1) HD Audio with Audio Boost |
| Operating System | Support for Windows® 10 64-bit |
| Dimensions | 9.6 in x 8.9 in (24.4 cm x 22.5 cm) |
| Form Factor | m-ATX |
