Additional information
| CPU Support | Supports 9th / 8th Gen Intel® Core™ / Pentium® Gold / Celeron® processors |
|---|---|
| CPU Socket | LGA 1151 |
| Chipset | Intel® H310 Chipset |
| Graphics Interface | 1 x PCIe 3.0 x16 Slots |
| Display Interface | DVI-D, VGA – Requires Processor Graphics |
| Memory Support | 2 DIMMs, Dual Channel DDR4 up to 2666MHz (32GB Max) |
| Expansion Slots | 2 x PCIe x 1 slots |
| Storage | 4 x SATA 6Gb/s |
| SATA RAID | N/A |
| USB Ports | 4 x USB 3.1 (Gen1), 6 x USB 2.0 ports |
| LAN | Realtek® 8111H Gigabit LAN |
| Wireless + Bluetooth | N/A |
| Audio | 8-Channel (7.1) HD Audio with Audio Boost |
| Operating System | Support for Windows® 10 64-bit |
| Dimensions | 8.9 in x 7.3 in (22.6 cm x 18.5 cm) |
| Form Factor | m-ATX |
